Figure 3-13 Replacing The Front Plastic Cover - Silicon Graphics IRIS Indigo Owner's Manual

5. Replace the front plastic cover.
Place the bottom of the front cover in the guides on the bottom of the chassis.
Tilt the panel up to the chassis, as shown in Figure 3-13. The cover snaps in
place.
Replacing the Front Plastic Cover
Figure 3-13
6. Reconnect the cables to the connectors on the back of the system.
You are finished installing your new memory. Now you are ready to start up the system
and check that the system recognizes the new memory.
Adding SIMMs to the IRIS Indigo Workstation
53
