Replacing the CPU Module

To replace the CPU module on the Indigo R4000 family CPU board, follow these
instructions:
1. Locate the CPU module.
Note:
The CPU module on your workstation may look different than the one shown
in Figure 6-24.
The CPU module is the large elevated module on the CPU board. It is protected
by a metal shield.
2. Ground yourself to the metal part of the CPU board.
Keeping the wrist strap around your wrist, attach the alligator clip to a metal
part of the CPU board.
Ordering, Removing and Installing Parts
145
