Chapter 6: Troubleshooting
Figure 6-20
The Toolchests
142

Shutting Down the System

To shut down the system, follow these steps:
1. Shut down and turn off the system.
From the System toolchest, choose "System Shutdown." The toolchests are
shown in Figure 6-20.
Turn off the power switch on the back of the Indigo chassis.
2. Disconnect the cables from the back of the workstation.
Make sure to disconnect the black power cable.

Removing the Covers and CPU Board

Once the system is shut down and all the cables are disconnected, follow these steps:
1. Remove the plastic front cover.
Face the front of the Indigo chassis.
Two tabs on top of the front cover hold it in place.
Press down on the tabs and pull the panel away from the chassis, as shown in
Figure 6-21.
Figure 6-21 Removing the Plastic Cover From the Indigo Chassis
