Chapter 2: Getting Started
24
10. Connect the system power cable, as shown in Figure 2-13.
The system power cable is black.
Caution: Make sure the power switch is OFF before plugging in your workstation.
The power switch is off when the "O" is pressed down.
Connect the female end of the power cable to the power connector on the back
of the chassis.
Plug the male end into a three-prong grounded electrical outlet, as shown in
Figure 2-13.
O
Figure 2-13 Connecting the Power Cable
Congratulations! You have finished connecting the IRIS Indigo parts and are ready to
power up the system.
