Chapter 6: Troubleshooting
152

Removing the Covers and Power Supply

Once the system is shut down and all the cables are disconnected, follow these steps:
1. Remove the plastic front cover.
Face the front of the Indigo chassis.
Two tabs on top of the front cover hold it in place.
Press down on the tabs and pull the panel away from the chassis, as shown in
Figure 6-30.
Figure 6-30 Removing the Plastic Cover of the Indigo Chassis
