Chapter 6: Troubleshooting
160
2. Remove the front cover.
Face the front of the Indigo chassis.
Two tabs on top of the front cover hold it in place.
Press down on the tabs and pull the cover away from the chassis, as shown in
Figure 6-36.
Removing the Front Plastic Cover of the Indigo Chassis
Figure 6-36
3. Remove the drive.
Push the green lever below the drive all the way to the left.
This should release the drive.
Pull the drive all the way out of the slot.

Installing the New Drive

To install the new drive, follow the instructions in "Installing Internal Drives" in
Chapter 4.
