List of Tables

Cable Connector Pinout Assignments for the Printer/Modem/Dumb
Table 4-1
Terminal Serial Cable 86
Cable Connector Pinout Assignments for the Modem Cable 87
Table 4-2
Cable Connector Pinout Assignments for the Adapter Cable 88
Table 4-3
Cable Connector Pinout Assignments for the PC Adapter Cable 89
Table 4-4
Troubleshooting Symptoms and Probable Causes 112
Table 6-1
ANSI/HFS 100-1988 Guidelines for VDT Workplace Adjustment 167
Table 7-1
Workstation Adjustments Preferred by CAD Users 169
Table 7-2
4D Compatible Pin Assignments (RS-232) 181
Table A-1
Macintosh SE Compatible Pin Assignments (RS-422) 182
Table A-2
Parallel Port (25-pin DSUB Connector) 182
Table A-3
Ethernet AUI Port (Thicknet) 184
Table A-4
Keyboard Port (6-pin MINIDIN on the keyboard)) 185
Table A-5
SCSI Port 186
Table A-6
Audio Ports 188
Table A-7
