Caution: The CPU board is extremely sensitive to static electricity; you must wear
the wrist strap provided with the system while removing it. The wrist strap prevents
the flow of static electricity, which could damage the board.
2. Ground yourself to the metal part of the chassis.
Put the wrist strap over your wrist, making sure it's tight against your arm.
Then attach its alligator clip to a metal part of the chassis. The notch above the
top drive slot works well.
3. Open the front metal panel.
A thumbscrew holds the metal panel in place.
Loosen the panel by unscrewing the thumbscrew, as shown in Figure 3-3.
You may need a screwdriver to loosen the screw.
Tilt the panel down until it rests on the flat surface.
Figure 3-3 Opening the Front Metal Panel
Adding SIMMs to the IRIS Indigo Workstation
