4. Replace the front metal panel.
Tilt the metal panel back up to the Indigo chassis, as shown in Figure 6-27.
Figure 6-27 Tilting the Metal Panel Up to the Chassis
Screw the thumbscrew back in to secure the panel. The panel should be snug
against the chassis.
Ordering, Removing and Installing Parts
149
