Replacing Internal Drives

To replace an internal drive, you'll power down the system, remove the covers and then
the drive, install the new drive, and power up the system. Internal drives include the
system disk drive, a secondary hard disk drive, a floppy or floptical disk drive, and a
DAT drive.
Caution: Drives are sensitive pieces of equipment. Handle your drive carefully. Do not
drop it or otherwise abuse it.

Removing the Drive

To remove the drive, follow these steps:
1. Power down the system.
Choose "System Shutdown" from the System menu in the Toolchest.
The Toolchest is in the upper left corner of your screen.
Turn off the power switch on the back of the workstation, as shown in
Figure 6-35.
O
Turning off the Power Switch
Figure 6-35
Replacing Internal Drives
159
