2. Slide the board into the chassis.
Slide in the board almost all the way.
Make sure the notch in the top lever goes under the top edge of the chassis.
3. Return the levers to their original positions. They should snap into place.
4. Replace the front metal panel.
Tilt the metal panel back up to the Indigo chassis, as shown in Figure 3-25.
Tilting the Metal Panel Up to the Indigo Chassis
Figure 3-25
Screw the thumbscrew back in to secure the panel. The panel should be snug
against the chassis.
Removing Memory
63
