Chapter 4: Installing Peripherals
80
5. Connect one end of the power cable that came with your device to the power
connector on the back of the device, as shown in Figure 4-11.
Power
button
Power
cable
Figure 4-11 Power Cable and Power Switch on the Back of the SCSI Drive
6. Plug the other end of the power cable into a grounded three-prong electrical outlet.
7. Turn the device on.
The power button is on the back of the device, as shown in Figure 4-11.
Note: Remember to turn on the external devices first and then your system to make sure
the devices are recognized.

Testing the External Device

After you've attached the device to your system, check to make sure your system
recognizes the device.
The system automatically sets up the system software for most external devices you
install and places an icon on the desktop.
