6. Connect the monitor power cable to the monitor and the IRIS Indigo chassis.
Pick up the monitor power cable. It is thick and beige and has a male and
female end.
Connect the female end of the cable to the power connector on the back of the
monitor.
Connect the male end of the cable to the monitor power connector on the back
of the chassis, as shown in Figure 2-10.
For voltage and frequency requirements, see the manual that came with
Note:
your monitor.
TUV
Figure 2-10 Connecting the Monitor to the Workstation with the Monitor Power Cable
Putting the Pieces Together
O
21
