3Com SuperStack 4 Configuration Manual page 293

Uploading Files by
means of TFTP
TFTP Client
Configuration Example
Table 350 Download Files by means of TFTP
Operation
Download files by means of TFTP tftp
To upload a file, the client sends a request to the TFTP server and then transmits
data to it and receives the acknowledgement from it. You can use the following
commands to upload files.
Perform the following configuration in User View.
Table 351 Upload Files by means of TFTP
Operation
Upload files by means of TFTP
Networking Requirement
The Switch serves as TFTP client and the remote PC as TFTP server. Authorized TFTP
directory is set on the TFTP server. The IP address of a VLAN interface on the Switch
is 1.1.1.1, and that of the PC is 2.2.2.2. The interface on the Switch connecting
the PC belong to the same VLAN.
The Switch application
download the
switch.app
to the TFTP server under the Switch directory for backup purpose.
config.cfg
Networking Diagram
Figure 75 Networking for TFTP Configuration
Switch Switch Switch
Configuration Procedure
1 Start TFTP server on the PC and set authorized TFTP directory.
2 Configure the Switch
Log into the Switch (locally through the Console port or remotely using Telnet).
<SW5500>
CAUTION: If the flash memory of the Switch is not enough, you need to first
delete the existing programs in the flash memory and then upload the new ones.
3 Enter System View and download the switch.app from the TFTP server to the flash
memory of the Switch.
<SW5500> system-view
Command
tftp-server
dest-file
]
Command
tftp-server
tftp
is stored on the PC. Using TFTP, the Switch can
switch.app
from the remote TFTP server and upload the
Network Network
TFTP Overview
get source-file [
source-file dest-file
put [
PC PC
305
]
