3Com SuperStack 4 Configuration Manual page 338

350 C 12: F S
HAPTER ILE YSTEM
Displaying and
Debugging SNMP
SNMP Configuration
Example
M
ANAGEMENT
If user disable NMP Agent, it will be enabled whatever
configured thereafter.
After the above configuration, execute the
display the running of the SNMP configuration, and to verify the effect of the
configuration.
Execute the debugging command in User View to debug SNMP
configuration.
Table 429 Display and Debug SNMP
Operation
Display the statistics information about
SNMP packets
Display the engine ID of the active device
Display the group name, the security
mode, the states for all types of views,
and the storage mode of each group of
the Switch.
Display the names of all users in the group
user table
Display the current community name
Display the current MIB view
Display the contact character string of the
system
Display the location character string of the
system
Display the version character string of the
system
Networking Requirements
Network Management Station and the Switch are connected via the Ethernet. The
IP address of Network Management Station is 129.102.149.23 and that of the
VLAN interface on the Switch is 129.102.0.1. Perform the following
configurations on the Switch: set the community name and access authority,
administrator ID, contact and Switch location, and enable the Switch to send trap
packet.
snmp-agent
command in all views to
display
Command
display snmp-agent statistics
display snmp-agent { local-engineid
| remote-engineid }
display snmp-agent group [
group-name ]
display snmp-agent usm-user [
engineid
engineid ] [ group
username
] [ username
display snmp-agent community [ read
| write ]
display snmp-agent mib-view [
exclude | include | viewname
mib-view
]
display snmp-agent sys-info contact
display snmp-agent sys-info
location
display snmp-agent sys-info version
command is
groupname
]
