Networking Requirements
In
Figure
69, it is required to configure the remote RADIUS authentication of Telnet
users.
One RADIUS server (as authentication server) is connected to the Switch and the
server IP address is 10.110.91.146. The password for exchanging messages
between the Switch and the authentication server is "expert". The Switch cuts off
the domain name from username and sends the remaining part to the RADIUS
server.
Networking Topology
Figure 69 Configuring the Remote RADIUS Authentication for Telnet Users
telnet user
Configuration Procedure
1 Add a Telnet user.
For details about configuring FTP and Telnet users, refer to User Interface
Configuration in the Getting Started chapter.
2 Configure remote authentication mode for the Telnet user, that is, scheme mode.
[SW5500-ui-vty0-4]authentication-mode scheme
3 Configure domain.
[SW5500]domain cams
[SW5500-isp-cams]quit
4 Configure RADIUS scheme.
[SW5500]radius scheme cams
[SW5500-radius-cams]primary authentication 10.110.91.146 1812
[SW5500-radius-cams]key authentication expert
[SW5500-radius-cams]server-type 3com
[SW5500-radius-cams]user-name-format without-domain
5 Configuration association between domain and RADIUS.
[SW5500-radius-cams]quit
[SW5500]domain cams
[SW5500-isp-cams]scheme radius-scheme cams
AAA and RADIUS Protocol Configuration
Authentication Servers
( IP address:10.110.91.164 )
Switch
289
Internet
Internet
