128 C 6: IP R
HAPTER OUTING
Displaying and
Debugging RIP
Example: Typical RIP
Configuration
P O
ROTOCOL PERATION
enabled, then traffic can be distributed equally among interfaces by employing
equivalent routes.
Table 129 Configuring RIP to Filter the Distributed Routes
Configuration Item
Enter System view
Enter RIP view
Enter RIP traffic sharing
among interfaces
After configuring RIP, enter the
configuration, and to verify the effect of the configuration. Enter the
command in User View to debug the RIP module. Enter the
View to reset the system configuration parameters of RIP.
Table 130 Displaying and Debugging RIP
Operation
Display the current RIP running state and
configuration information
Display RIP inteface information
Display RIP routing information
Enable the RIP debugging information
Disable the RIP debugging information
Enable the debugging of RIP receiving packet
Disable the debugging of RIP receiving packet
Enable the debugging of RIP sending packet
Disable the debugging of RIP sending packet
Reset the system configuration parameters of RIP
Networking Requirements
As shown in Figure
Ethernet port. The Ethernet ports of Switch A and Switch B are connected to the
networks 155.10.1.0 and 196.38.165.0 respectively. Switch C, Switch A and
Switch B are connected via Ethernet 110.11.2.0. Correctly configure RIP to ensure
that Switch C, Switch A and Switch B can interconnect.
Command
system-view
rip
traffic-share-across
-interface
command in any view to display the RIP
display
31, Switch C connects to the subnet 117.102.0.0 through the
Description
Required by default, RIP traffic
sharing among interfaces is
disabled
debugging
command in RIP
reset
Command
display rip
display rip interface
display rip routing
debugging rip packet
undo debugging rip packet
debugging rip receive
undo debugging rip receive
debugging rip send
undo debugging rip send
reset
