302 C 12: F S
HAPTER ILE YSTEM
M
ANAGEMENT
password hello and with read and write authority over the Switch root directory
on the PC. The IP address of a VLAN interface on the Switch is 1.1.1.1, and that of
the PC is 2.2.2.2. The Switch and PC are reachable.
The Switch application
download the
switch.app
to the FTP server under the Switch directory for backup purpose.
config.cfg
Networking Diagram
Figure 72 Networking for FTP Configuration
Switch Switch Switch
Configuration Procedure
1 Configure the FTP server parameters on the PC: a user named as Switch, password
hello, read and write authority over the Switch directory on the PC.
2 Configure the Switch
Log into the Switch (locally through the Console port or remotely using Telnet).
<SW5500>
CAUTION: If the flash memory of the Switch is not enough, you need to first
delete the existing programs in the flash memory and then upload the new ones.
Type in the right command in User View to establish FTP connection, then correct
username and password to log into the FTP server.
<SW5500> ftp 2.2.2.2
Trying ...
Press CTRL+K to abort
Connected.
220 WFTPD 2.0 service (by Texas Imperial Software) ready for new user
User(none):switch
331 Give me your password, please
Password:*****
230 Logged in successfully
[ftp]
3 Type in the authorized directory of the FTP server.
[ftp]cd switch
4 Use the command to upload the config.cfg to the FTP server.
put
[ftp]put config.cfg
5 Use the command to download the switch.app from the FTP server to the
get
flash directory on the FTP server.
[ftp]get switch.app
is stored on the PC. Using FTP, the Switch can
switch.app
from the remote FTP server and upload the
Network Network
PC PC
