QoS Profile
Configuration
QoS Profile
Configuration
3 Relabel ef priority for PC1 packets.
[SW5500-Ethernet1/0/1]traffic-priority inbound ip-group 2000 dscp ef
When used together with the 802.1x authentication function, the QoS profile
function can offer preconfigured QoS settings for a qualified user in
authentication (or a group of users).
When the user passes the 802.1x authentication, the Switch delivers the right
profile dynamically to the port from which the user is accessed after referring to
the mapping between user names and profiles stored on the AAA server.
The QoS profile function can offer packet filtering, traffic policing and preference
replacing functions together.
Figure 54 QoS Profile Configuration Environment
QoS profile configuration details:
Table 248 QoS Profile Configuration
Device Configuration
AAA server Configure user
authentication
information
Configure mapping
between user names and
QoS profile
Switch Enable 802.1x
authentication function
Define application mode
on the port of QoS profile
Configure QoS profile,
including packet filtering,
traffic policing and
preference replacing
Apply QoS profile to the
port
Network
Network
Switch
AAA Server
User
Default
––
––
––
Port-based
mode
––
––
QoS Profile Configuration
Description
––
Multiple users can correspond to
the same QoS profile.
Refer to the Security part of this
manual for detailed
configuration.
You can change it to user-based
mode
First define an ACL and then
configure the QoS function.
Refer to the ACL chapter of the
QoS/ACL module for defining
ACL
You can apply the QoS profile
actions to the current port with
the right commands.
