3C
M

Summary of Software Features

This table summarizes the software features that are supported by the Switch 4050 and 4060 .
Feature
Automatic IP Configuration
Resilient Links
Aggregated Links
Broadcast Storm Control
Virtual LANs (VLANs)
Multicast Filtering
Rapid Spanning Tree Protocol
Layer 3 Routing Protocol
Webcache Support
Quality of Service (QoS)
Email Notification of Events
RMON
Management
For further information on how each of these features operate on your Switch, refer to the
Implementation Guide for your Switch.
S
OM
WITCH
ANAGEMENT
4050
4060
AND
Q
R
UICK
EFERENCE
Switch 4050/4060
Supported
Supported
Support for four groups of four ports per unit
Supported
Support for up to 30 VLANs using the IEEE 802.1Q standard
128 Multicast filter groups supported
IGMP filtering supported
Supported
Supported
Supported
Supported
Supported
Seven groups supported: Statistics, History, Alarms, Hosts, Hosts
Top N, Matrix, Events
Web interface, Command Line Interface, and SNMP supported
1
G
UIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the SWITCH 4050 and is the answer not in the manual?

Questions and answers

Related Manuals for 3Com SWITCH 4050

Summary of Contents for 3Com SWITCH 4050

  • Page 1: Summary Of Software Features

    ANAGEMENT Summary of Software Features This table summarizes the software features that are supported by the Switch 4050 and 4060 . Feature Automatic IP Configuration Resilient Links Aggregated Links Broadcast Storm Control Virtual LANs (VLANs) Multicast Filtering Rapid Spanning Tree Protocol...
  • Page 2 Web Interface Map – Device View...
  • Page 3 Top-level Device View System Bridge Physical Interface Protocol Security Web Interface Device Mimic For example purposes only, this graphic shows a Switch 4060. Protocol Folder IP Folder Setup Interface Route UDP Helper ARP Folder Aging Display/Edit Find Flush Statistics Interface Folder Display/Edit Rip Folder Display/Edit...
  • Page 4 A Quick Guide to the Web Interface Operations This table describes the operations that are available in the Web Interface. Operation System Getting Started System Console Setup System Control Initialize System Control Reboot System Control Software Upgrade System Management Setup System Management Alert Create System Management Alert Modify System Management Alert Test...
  • Page 5 Operation (Continued) Bridge Resilient Links Create Bridge Resilient Links Delete Bridge Resilient Links Modify Bridge Resilient Links Summary Bridge Spanning Tree Setup Physical Interface Ethernet History History-1 Hour Physical Interface Ethernet History History-48 Hours Physical Interface Ethernet Setup Physical Interface Ethernet Smart Autosensing Physical Interface Ethernet Statistics Physical Interface Ethernet Summary Protocol IP Setup...
  • Page 6 Command Line Interface Map To display sub-menus: At the Select menu option prompt, enter the name of the menu or menus. To display parent menus: At the Select menu option prompt, enter q. Bridge Menu Top-level Menu bridge feature logout physicalInterface protocol security...
  • Page 8 A Quick Guide to the Command Line Interface Commands This table describes the commands that are available in the Command Line Interface. Command bridge addressDatabase add bridge addressDatabase agingTime bridge addressDatabase find bridge addressDatabase remove bridge addressDatabase summary bridge broadcastStormCont bridge linkAggregation detail bridge linkAggregation modify addPort bridge linkAggregation modify linkState...
  • Page 9 Command (Continued) bridge vlan delete bridge vlan detail bridge vlan modify addPort bridge vlan modify name bridge vlan modify removePort bridge vlan summary feature cacheConfig addCache feature cacheConfig disableCache feature cacheConfig enableCache feature cacheConfig exclusion addExclusion feature cacheConfig exclusion disableExclusion feature cacheConfig exclusion enableExclusion feature cacheConfig exclusion removeExclusion feature cacheConfig exclusion summary...
  • Page 10 Command (Continued) protocol ip ping protocol ip rip authentication protocol ip rip mode protocol ip rip neighbors protocol ip rip poisonReverse protocol ip rip receiveMode protocol ip rip resetStats protocol ip rip sendMode protocol ip rip statistics protocol ip rip summary protocol ip rip updateTime protocol ip route add protocol ip route default...
  • Page 11 Command (Continued) system management alert create system management alert delete system management alert modify system management alert removeAddress system management alert summary system management alert test system management contact system management location system management monitor modify system management monitor summary system management name system management password system management remoteAccess...
  • Page 12 Command (Continued) trafficManagement qos serviceLevel modify trafficManagement qos serviceLevel summary trafficManagement qos trafficQueue modify trafficManagement qos trafficQueue summary What does the Command do? Modifies a service level. Displays summary information on service levels. Modifies the number of traffic queues. Displays summary information on traffic queues. Part Number: DQA1770-9AAA02 Published: June 2002...
