System 5 Digital Audio Mixing System Operation Manual
5.3

Solo

System 5 has an extensive solo control system that is accessed from the center section.
Press the Solo Ctrl switch in the master Solo section to display the Solo Control Panel.
Solo
LR phase
Figure 5-9 Master Solo section (top-left) and Solo Control Panel
5.3.1

Solo Mode

The three Solo modes can be selected by pressing their respective switches in the Solo
Control Panel. Selecting one mode deselects the previous mode.
APL (After-Pan Listen): Signal is post-fader and pan (stereo)
PFL (Pre-Fader Listen): Signal is pre-fader in mono
SIP (Solo-In-Place): Allows Solo channels through to the mix busses. Mutes all channels
not soloed but not channels designated Solo-Safe (page 76). This mode allows monitor-
ing soloed channels with panning and effects if the effects returns have been designated
Solo-Safe. We do not recommend this destructive solo mode for live broadcast or for
recording a mix or dub.
Film Mode: Switches any mix busses in playback to bus temporarily so an SIP solo can
be heard.
L4
Solo
L3
Ctrl
L2
L1
Comms
T2
Ctrl
T1
CR
Output
74
CM401 Master Section
Solo
Film Mode
Backstop PFL
Momentary
Solo-Safe
Summing DimCR
I/C
Solo>None
APL
Solo>Alt1
Solo>Alt2
PFL
Solo>Flw
SIP
Clear
Main
Panel
New Mod Clr Name
Info
