Fill Start + Fill End; Setting Fill Start And End Times; Setting Times In The Machine Control Panel - Euphonix System 5 Operation Manual

System 5 Digital Audio Mixing System Operation Manual
14.8.4

Fill Start + Fill End

1. Press Fill End then Fill Start in the center section automation panel.
Both keys should be illuminated.
2. Punch in the parameter and adjust the control to the desired level.
3. Punch out and the level at that time is written throughout the mix.
Using Fill Start and Fill End together is a useful way to set a static value all the way
through the mix.
14.8.5

Setting Fill Start and End Times

The Fill Region features, discussed in the next sections, require setting the AR/Start and
AR/End time fields in Automation Panel Page 1. The Fill Region key must be lit for
these times to be used.
1. From the Main Panel, press the Automation button to display Automation
Panel Page 1.
2. Enter a timecode into the locate time display using the numeric keypad on the
center section (Figure 14-13). The entire time must be entered, beginning with
frames. When the first numeric key is pressed, the display clears to enter the
new value.
A time can also be entered by recalling a Cue (see Cue Points on page 152).
3. Press Store Locate and then the AR/Start key in Automation Panel Page 1
to transfer the locate time to the AR/Start field.
4. Enter the AR/End time into the locate time display by repeating step 2.
5. Press Store Locate and then the AR/End key in Automation Panel Page 1 to
transfer the locate time to the AR/End field.
Fill
Time
00:12:24:03
Display
hr
00:16:11:04
_
+ Delete
7 8 9
Figure 14-13 Setting times in the machine control panel
Fill
min sec / ft Fr/ms
bar beat Tick
locate time
Locat e
Trim
Trim
Edit
Reg's
-
+
Stor e Stor e
Cue
Recall
Current
Locat e
194
Dynamic Automation
