System 5 Digital Audio Mixing System Operation Manual
7.2.8

Bus Master Inserts

Each Group, Mix, and Aux Bus has an insert point. See Mix Bus Send/Return on page
50 to learn about bus insert send and returns specified in PatchNet. Switching the insert
in/out works the same for Aux, Mix, and Group busses.
1. Press the Aux Mstrs, Grp Mstrs, or Mix Mstrs button to display that bus on
the Bus Master knobset.
2. Press both cfg
3. Press the lower button to the left of the knob to activate that bus insert (In: but-
ton lit). Press the button again to deactivate the bus insert (Out: button not lit).
7.3

Mix and Group Bus Setup

See Busses on page 52 to learn about how to configure the Mix and Group Busses.
and keys simultaneously.
94
Busses and Bus Masters
