SECTION 4 : MISC ENHANCEMENTS
Dynamics
3.1
Headroom
Extension
Multiple Console
3.1
Solo Linking
Euphonix CS3000/2000 MixView 3.2 Software Supplement
With a required hardware modification, ES108A Dynamics gain can be ad-
justed to provide 6dB more headroom capacity over a stock console with
MixView 3.1. This option is recommended for users that have experienced
problems in dealing with transient dynamic signals and provides more gain
before clipping, standardizing the headroom between the console and the
Dynamics modules. For information on this modification, please call Euphonix
customer support.
With a required hardware modification, the console's Solo bus logic may be
linked across multiple consoles. This provides dual-operator systems the
ability to operate the two Solo buses as if they were one. Setup is accom-
plished with the new Ext Solo menu. From the Solo menu, press [F2] (Ext Solo):
Solo Menu
BPFL
F1
Ext Solo Menu
Resync
F1
Note: In the event that the Solo bus logic between consoles become
unsynchronized, i.e., one console is in solo and the other isn't, the consoles
may be re-synced by pressing [F1] (Resync) in the Ext Solo menu. The F1 key
function is renamed "Resync" whenever Ext Solo is set ON.
Setup logic for the originating console is as follows (x = feature set ON):
Normal mode Kill mode
x
x
The following steps should be done on all consoles to be linked in order to
ensure successful operation of this feature:
1. From the Ext Solo menu, press [F1] (Resync);
2. Set both consoles to the same solo mode (see table above for modes).
Note: Consoles may be configured for different Solo modes but this is not
recommended as the potential for confusion is greatly increased.
Ext Solo
F2
F3
F4
Ext Solo : ON
F2
F3
F4
Inter-cancel
x
x
x
x
Section 4: Misc Automation
Signal result
uses Ext Solo bus
sums to Ext Solo bus
uses Stereo Program bus
sums to Stereo Program bus
1 - 11
