System 5 Digital Audio Mixing System Operation Manual
11.2.4

Rename a Snapshot

1. Press the Name key at the bottom of the Snapshot Panel so it begins flashing.
2. Press the key corresponding to the Snapshot to rename.
That key flashes.
3. Use the console keyboard to rename the Snapshot (eight characters maximum).
4. Press the Enter key on the keyboard, the Snapshot's key, or Name key again
to store the new name and exit the process.
11.2.5

Delete a Snapshot

1. Press the Clr key at the bottom of the Snapshot Panel so it begins flashing.
2. Press the key corresponding to the Snapshot to delete.
That key's display darkens and the name returns to the default (i.e., SS #).
NOTE: A Snapshot must be deleted before its location can be used again.
146
Layouts and Snapshots
