System 5-B Digital Audio Mixing System Operation Manual
5.3

Solo

System 5-B has an extensive solo control system that is accessed from the center sec-
tion. Press the Solo Ctrl switch in the master Solo section to display the Solo Control
Panel.
Solo
LR phase
Figure 5-9 Master Solo section (top-left) and Solo Control Panel
5.3.1

Solo Mode

The three Solo modes can be selected by pressing their respective switches in the Solo
Control Panel. Selecting one mode deselects the previous mode.
APL (After-Pan Listen): Signal is post-fader and pan (stereo)
PFL (Pre-Fader Listen): Signal is pre-fader in mono
SIP (Solo-In-Place): Allows soloed channels through to the main busses. Mutes all chan-
nels not soloed but not channels designated as Solo-Safe (page 69). This mode allows
monitoring soloed channels with panning and effects if the effects returns have been
designated Solo-Safe. We do not recommend this destructive solo mode for live broad-
cast or for recording a mix or dub.
L4
Solo
L3
Ctrl
L2
L1
Comms
T2
Ctrl
T1
CR
Output
67
CM401 Master Section
Solo
Backstop PFL
Momentary
Solo-Safe
Summing
I/C DimCR
Solo>None
APL
Solo>Alt1
Solo>Alt2
PFL
Solo>Flw
SIP
Clear
Main
Panel
New Mod Clr Name
Info
