Compressor/Expander (Page 1)
The knobs have four compressor and four expander parameters (Figure 8-12). The
knobs with two parameters listed (i.e., cThr/cKne) toggle between parameters by
pressing the upper switch to the left of the knob.
The lower switch next to the cRat knob switches the compressor in/out. The lower
switch next to the xRat knob switches the expander in/out.
Compressor In/Out
Expander In/Out
CRel
CAtk
CThr
CKne
CRat
XRel
XHld
XAtk
XThr
XKne
XRat
cfg
Figure 8-12 Dynamics knobset page 1
115
Page keys display
Expander/Gate, Compressor
and Sidechain pages
Channels and Strips
