System 5 Digital Audio Mixing System Operation Manual
To display the configuration controls for processor order and patch points:
1. Press the Input function key to assign the Input controls to the knobs.
2. Press both cfg
patching and processor order on the knobset.
The cfg keys flash in configuration mode.
3. Use the
8.3.1

Channel Patch Points

The first configuration page allows sources to be assigned to the Key, A, and B inputs.
Each input has identical controls.
All patch points can be set in PatchNet (see Console I/O on page 44).
To change the source to the A input:
1. Press the A Input knob switch.
A scrolling list appears on the TFT display above the Strip.
2. Use the switches to the left of the knob to display other groups of sources.
These switches function as page up/down keys in this mode.
Each group is an internal digital or MADI connection that can contain up to 56
audio sources. For example, one group could be mic inputs, another inputs
from a digital multitrack machine.
3. When the desired group is located, use the knob to scroll the list to highlight
the correct input.
4. Press the knob switch to select that input.
5. Exit configuration mode by pressing both cfg
stop flashing).
keys simultaneously to display the configuration pages for
keys individually to display the two configuration pages.
109
Channels and Strips
keys simultaneously (they
