Chapter 12: Machine Control

The Machine Control Panel in the center section contains System 5's Transport and
Locate functions.
12:24.03.10
Time
Display
hr min
bar
00:16.12.04
Mark
In
locate time
-
Delete
+
7 8 9 Cue
4 5 6
1 2 3
0
Clear Enter
Shuttle
L o c Trim
Roll
Back
Figure 12-1 Machine Control Panel
