System 5 Digital Audio Mixing System Operation Manual
15.3.2

Joystick Assign Mode

Cycle: Selecting a channel using the Wave key assigns it to the left joystick. Selecting
a second channel within 2.5 s assigns it to the right joystick.
Direct Assign: Hold a channel's Wave key down and select Pan To: to assign that
channel to the left joystick. Hold the Wave key down and select the Pan knobset key
to assign the channel to the right joystick.
402 Cycle: Assigns channels to the joystick using the channel select keys on the
CM402's channel select panel. Selecting a channel assigns it to the left joystick. Select-
ing a second channel within 2.5 s assigns it to the right joystick.
15.3.3

Layouts

Joystick assignments can be stored/recalled with Layouts and can also be protected
from Layouts using Strip Lock in the Strip Config Panel (see page 101).
15.3.4

Setting the Automation Mode for a Joystick

Set the automation mode for pan and surround parameters controlled by the joystick the
same as a standard strip: Hold down the joystick's Wave key and press its Select/Punch
key repeatedly to cycle through the automation modes (Isolate, Write Absolute, Read).
The automation mode can also be set by pressing the desired automation mode key on
the CM401 (i.e., Write Abs), which puts the console into a select mode. Then press the
joystick's Select/Punch key.
Strip Config 3

Joystick Assign Mode

Cycle
Direct Assign
402 Cycle
Figure 15-11 Joystick Assign Mode
221
CM403 Film/Post Module
