System 5 Digital Audio Mixing System Operation Manual
Aux Send Config
Aux Sends may be individually set to pre- or post-fader or can be easily set globally.
To set each Aux Bus individually:
1. Press the Aux function key to display the Aux Bus knobset.
2. Press both cfg
page.
The keys flash to indicate config mode.
3. Press the lower-left button beside each Gain knob to toggle the pre- or post-fader
status for that send (or pair for stereo).
The button lights green to indicate post-fader and does not light for pre-fader.
All Aux busses are set to post-fader by default.
To set multiple Aux sends to receive their channels pre- or post-fader:
1. Hold down a Strip's Wave key and press the Clear key at the top of that Strip
(above the top knob's display) to activate All mode.
All appears above Clear.
2. Press the Aux function key on that Strip to display Aux on all knobsets.
3. Press both cfg
The Pre/Post Fader Config page is displayed on all knobsets. The cfg
flash to indicate config mode.
4. Press the pre/post keys (lower-left button) for each Aux send you wish to set.
5. Repeat for each channel
Another option is to copy/paste to other channels. After setting one channel to the desired
pre/post status for each Aux Send in Step 4 above:
1. Press and hold down the Wave key and press the
just set.
The channel dims to show it awaits selection of items to copy.
2. Press the Strip's Aux switch to select all Aux parameters (pre/post, levels, and
on/off states).
3. On the channel you wish to paste to, press and hold down the Wave key and
press the Paste
After the first paste, the copied channel undims but you can continue pasting to
other channels.
keys simultaneously to display the Pre/Post Fader Config
keys simultaneously on that Strip.
key.
122
Channels and Strips
keys
Copy key on the channel
