System 5 Digital Audio Mixing System Operation Manual
14.4.3

Strip Mode/Strip Function

Assign a locally selected automation mode to an entire function or individual parameters
on a Strip. For example, with EQ already assigned to the knobset:
1. Select a local automation mode by simultaneously pressing the Wave key and
the Select/Punch key for the control you wish to assign.
The screen above the Strip displays a popup menu of the automation modes.
The currently active mode is highlighted in green, the other modes in yellow.
2. While still holding down the Wave key, press the Knobset Select/Punch key at
the top-right of the Strip or at the top of the Strip's function keys (Figure 14-4)
repeatedly until the desired mode is highlighted.
This assigns the selected automation mode to the entire knobset. Press a knob's
Select/Punch key instead of the Knobset Select/Punch key to assign the mode
to that knob only.
14.4.4

Changing the Automation Mode of an Individual Parameter

Change the automation mode of an individual parameter, even if it has been assigned
globally:
1. Simultaneously press the Wave key and Select/Punch key for the parameter
you wish to modify.
The screen above the Strip displays a popup menu of the automation modes.
2. While holding down the Wave key, press the Select/Punch key repeatedly
until the desired mode is highlighted.
3. Release both keys to select the last mode highlighted.
NOTE: Toggling the automation mode is closely related to setting the Glide settings.
Continuing to hold down the Wave key and repeatedly pressing the Select/
Punch key cycles through the automation modes. To toggle the Glide setting,
be sure to press the Select/Punch key once and then release both keys.
180
Dynamic Automation
