x Stack
Download Configuration, Upload Configuration, Upload Log, and Upload Attack Log.
RCP Server IPv4
Enter the IP address of the RCP Server.
Address
User Name Enter the remote user name on the RCP server.
Local File Name Enter the file name in the field. Tick the Increment, and the existing configuration will not be
cleared before applying the new configuration.
Unit Number Select the switch in the switch stack from which, or to which to upload or download files. Tick the
ALL check box to denote all switches in the switch stack.
Image ID Use the pull-down menu to select the Image file ID.
Configuration ID Use the pull-down menu to select the configuration file ID.
Filter This is used to filter the configuration data that relates to upload configuration.
Click Apply to implement the changes.

Ping Test

Ping is a small program that sends ICMP Echo packets to the IP address you specify. The destination node then responds to or
"echoes" the packets sent from the Switch. This is very useful to verify connectivity between the Switch and other nodes on the
network.

IPv4 Ping Test

The following window is used to Ping an IPv4 address.
To view this window, click Administration > Ping Test > IPv4 Ping Test as shown below.
The following parameters can be configured:
Parameter Description
®
DGS-3400 Series Layer 2 Gigabit Ethernet M anaged Sw itch
Figure 2 - 45 IPv4 Ping Test window
50
