The following parameters can be set:
Parameter Description
Unit
Select the unit to configure.
From / To
Use the pull-down menu to select a range of ports to be configured.
Notification State
Use the pull-down menu to Enable or Disable the status of the LLDP notification. This function
controls the SNMP trap, however it cannot implement traps on SNMP when the notification is
disabled.
Admin Status
This function controls the local LLDP agent and allows it to send and receive LLDP frames on
the ports. This option contains TX_Only, RX_Only, TX_and_RX or Disabled.
TX_Only – The local LLDP agent can only transmit LLDP frames.
RX_Only – The local LLDP agent can only receive LLDP frames.
TX_and_RX – The local LLDP agent can both transmit and receive LLDP frames.
Disabled – The local LLDP agent can neither transmit nor receive LLDP frames.
The default value is TX_and_RX.
Port Description
Used to enable or disable the port description on the Switch.
System Name
Used to enable or disable the system name on the Switch.
System
Used to enable or disable the system description on the Switch.
Description
System
Used to enable or disable the system capabilities on the Switch.
Capabilities
Click Apply to implement the changes.

802.1 Extension LLDP Port Settings

This window is used to configure an individual port or group of ports to exclude one or more of the IEEE 802.1 organizational
port VLAN ID TLV data types from outbound LLDP advertisements.
To view this window, click L2 Features > LLDP > 802.1 Extension LLDP Port Settings, as shown below.
®
