Reauthenticate Port(S) - D-Link DGS-3427 - xStack Switch - Stackable Product Manual

x Stack
From / To Select ports to be initialized.
MAC Address
The MAC address of the Switch connected to the corresponding port, if any.
Port A read-only field indicating a port on the Switch.
Auth PAE State The Authenticator PAE State will display one of the following: Initialize, Disconnected,
Connecting, Authenticating, Authenticated, Aborting, Held, ForceAuth, ForceUnauth, and N/A.
Backend State The Backend Authentication State will display one of the following: Request, Response,
Success, Fail, Timeout, Idle, Initialize, and N/A.
Port Status The status of the controlled port can be Authorized, Unauthorized, or N/A.
Click Apply to implement the changes.

Reauthenticate Port(s)

This window allows reauthentication of a port or group of ports by using the pull-down menus From and To and clicking Apply.
The Reauthenticate Port Table displays the current status of the reauthenticated port(s) once Apply has been clicked.
To view this window, click Security > 802.1X > Reauthenticate Port(s), as shown below.
Figure 6 - 31 Reauthenticate Port window (Port-based 802.1X)
To reauthenticate ports for the MAC side of 802.1X, the user must first enable 802.1X by MAC address in the DGS-3600 Web
Management Tool window.
Click Security > 802.1X > Reauthenticate Port(s), as shown below.
®
DGS-3400 Series Layer 2 Gigabit Ethernet M anaged Sw itch
NOTE: The user must first globally enable 802.1X in the DGS-3400 Web
Management Tool window before initializing ports. Information in the
Initialize Ports Table cannot be viewed before enabling 802.1X.
NOTE: The user must first globally enable 802.1X in the DGS-3400 Web
Management Tool window before initializing ports. Information in the
Initialize Ports Table cannot be viewed before enabling 802.1X.
300
