LLDP Management Address Table

The following window is used to set up LLDP management address settings on the Switch.
To view this window, click L2 Features > LLDP > LLDP Management Address Settings, as shown below.
The following parameters can be set or displayed:
Parameter
Address Type
Address
Click Find to display the entry.

LLDP Local Port Table

LLDP Local Port Table window displays the information on a per port basis currently available for populating outbound LLDP
advertisements in the local port brief table shown below.
To view this window, click L2 Features > LLDP > LLDP Local Port Table, as shown below.
®
DGS-3400 Series Layer 2 Gigabit Ethernet M anaged Sw itch
Figure 3 - 67 LLDP Management Address window
Description
Use the drop-down menu to toggle between IPV4 Address and IPV6 Address.
Enter the LLDP management address in this field.
