Click Apply to implement the changes.

LLDP Management Address Settings

This window is used to configure the LLDP management address information on the Switch.
To view this window, click L2 Features > LLDP > LLDP Management Address Settings, as shown below.
®
DGS-3400 Series Layer 2 Gigabit Ethernet M anaged Sw itch
This specifies that the LLDP agent should transmit 'Power via MDI TLV'. Three IEEE 802.3
PMD implementations (10BASE-T, 100BASE-TX, and 1000BASE-T) allow power to be
supplied over the link for connected non-powered systems. The Power Via MDI TLV allows
network management to advertise and discover the MDI power support capabilities of the
sending IEEE 802.3 LAN station. The default state is Disabled.
The Link Aggregation option indicates that LLDP agents should transmit 'Link Aggregation
TLV'. This indicates the current link aggregation status of IEEE 802.3 MACs. More precisely,
the information should include whether the port is capable of doing link aggregation, whether
the port is aggregated in an aggregated link, and what is the aggregated port ID. The default
state is Disabled.
The Maximum Frame Size indicates that LLDP agent should transmit 'Maximum-frame-size
TLV. The default state is Disabled.
202
