x Stack
Enter a name for the new interface to be added in the Interface Name field (if editing an IP interface, the Interface Name will
already be in the top field as seen in the window above). Enter the interface's IP address and subnet mask in the corresponding
fields. Pull the Interface Admin State pull-down menu to Enabled and click Apply to enter to make the IP interface effective. To
view entries in the IP Interface Settings, click the
Changes to enter the changes into NV-RAM.
The following fields can be set or modified:
Parameter
Interface Name
IP Address
Subnet Mask
VLAN Name
Interface Admin. State
Secondary
Proxy ARP
Proxy Local ARP
IP Directed Broadcast
Click Apply to implement the changes.
®
DGS-3400 Series Layer 2 Gigabit Ethernet M anaged Sw itch
Figure 2 - 5 IPv4 Interface Settings - Edit window
Show All IP Interface Entries
Description
This field displays the name for the IP interface or it is used to add a new interface created
by the user. The default IP interface is named "System".
This field allows the entry of an IPv4 address to be assigned to this IP interface.
This field allows the entry of a subnet mask to be applied to this IP interface.
This field displays the VLAN name directly associated with this interface.
Use the pull-down menu to enable or disable configuration on this interface.
Use the pull-down menu to set the IP interface as True or False. True will set the interface
as secondary and False will denote the interface as the primary interface of the VLAN
entered above. Secondary interfaces can only be configured if a primary interface is first
configured.
Use the pull-down menu to enable or disable the proxy ARP state on the IP interface.
Use the pull-down menu to enable or disable the proxy local ARP. This function allows the
Switch to respond to the proxy ARP, if the source IP and destination IP are in the same
interface.
Use the pull-down menu to enable or disable the IP directed-broadcast state of a specified
interface.
NOTE: The Switch's factory default IP address is 10.90.90.90 with a
subnet mask of 255.0.0.0 and a default gateway of 0.0.0.0.
17
hyperlink. Use the Save Services > Save
