Managing FLOGI, Name Server, FDMI, and RSCN Databases
D2, and H belong to the same zone. If disks D1 and D2 are online at the same time, one of the following
actions applies:
• The multi-pid option is disabled on switch 1— Two RSCNs are generated to host H: one for the disk
• The multi-pid option is enabled on switch 1—A single RSCN is generated to host H, and the RSCN
Note Some Nx ports may not support multi-pid RSCN payloads. If so, disable the RSCN multi-pid option.

Configuring the multi-pid Option

To configure the multi-pid option, perform this task:
Procedure
Step 1
Step 2

Suppressing Domain Format SW-RSCNs

A domain format SW-RSCN is sent whenever the local switch name or the local switch management IP
address changes. This SW-RSCN is sent to all other domains and switches over the ISLs. The remote switches
can issue GMAL and GIELN commands to the switch that initiated the domain format SW-RSCN to determine
what changed. Domain format SW-RSCNs can cause problems with some non-Cisco SAN switches.
To suppress the transmission of these SW-RSCNs over an ISL, perform this task:
Procedure
Step 1
Step 2

Clearing RSCN Statistics

You can clear the counters and later view the counters for a different set of events. For example, you can keep
track of how many RSCNs or SW-RSCNs are generated on a particular event (such as ONLINE or OFFLINE
events). You can use these statistics to monitor responses for each event in the VSAN.
OL-16597-01
D1 and another for disk D2.
payload lists the affected port IDs (in this case, both D1 and D2).
Command or Action
switch# configuration terminal
switch(config)# rscn multi-pid vsan vsan-id
Command or Action
switch# configuration terminal
switch(config)# rscn suppress
domain-swrscn vsan vsan-id
Purpose
Enters configuration mode.
Sends RSCNs in a multi-pid format for the
specified VSAN.
Purpose
Enters configuration mode.
Suppresses transmission of domain format
SW-RSCNs for the specified VSAN.
Cisco Nexus 5000 Series Switch CLI Software Configuration Guide
Configuring the multi-pid Option
