Configuring Fibre Channel Interfaces

Configuring Global Attributes for Fibre Channel Interfaces

Configuring Switch Port Attribute Default Values

You can configure attribute default values for various switch port attributes. These attributes will be applied
globally to all future switch port configurations, even if you do not individually specify them at that time.
To configure switch port attributes, perform this task:
Procedure
Step 1
Step 2
Step 3
Step 4

About N Port Identifier Virtualization

N port identifier virtualization (NPIV) provides a means to assign multiple FC IDs to a single N port. This
feature allows multiple applications on the N port to use different identifiers and allows access control, zoning,
and port security to be implemented at the application level. The following figure shows an example application
using NPIV.
Figure 44: NPIV Example
OL-16597-01
Command or Action
switch# configuration terminal
switch(config)# no system default
switchport shutdown san
switch(config)# system default
switchport shutdown san
switch(config)# system default
switchport trunk mode auto
Configuring Global Attributes for Fibre Channel Interfaces
Purpose
Enters configuration mode.
Configures the default setting for administrative state of an
interface as Up. (The factory default setting is Down).
This command is applicable only to interfaces for
Tip
which no user configuration exists for the
administrative state.
Configures the default setting for administrative state of an
interface as Down. This is the factory default setting.
Tip This command is applicable only to interfaces for
which no user configuration exists for the
administrative state.
Configures the default setting for administrative trunk mode
state of an interface as Auto.
Note The default setting is trunk mode
on.
Cisco Nexus 5000 Series Switch CLI Software Configuration Guide
473
