Configuring vPCs
Step 3
Step 4
Step 5
This example shows how to configure an EtherChannel that will connect to the downstream device:
switch# configure terminal
switch(config)# interface port-channel 20
switch(config-if)# vpc 5

Manually Configuring a vPC Domain MAC Address

You create the vPC peer link by designating the EtherChannel that you want on each switch as the peer link
for the specified vPC domain. We recommend that you configure the EtherChannels that you are designating
as the vPC peer link in trunk mode and that you use two ports on separate modules on each vPC peer switch
for redundancy.
Before You Begin
Ensure that you have enabled the vPC feature.
You must configure both switches on either side of the vPC peer link with the following procedure.
Procedure
Step 1
Step 2
Step 3
OL-16597-01
Command or Action
switch(config-if)# vpc number
switch# show vpc brief
switch# copy running-config
startup-config
Command or Action
switch# configure terminal
switch(config)# vpc domain
domain-id
switch(config-vpc-domain)#
system-mac mac-address
Cisco Nexus 5000 Series Switch CLI Software Configuration Guide
Manually Configuring a vPC Domain MAC Address
Purpose
A vPC can be configured on a normal EtherChannel
Note
(physical vPC topology), on an EtherChannel fabric
interface (fabric extender vPC topology), and on an
EtherChannel host interface (host interface vPC
topology)
Configures the selected EtherChannel into the vPC to connect
to the downstream switch. The range is from 1 to 4096.
The vPC number that you assign to the EtherChannel
connecting to the downstream switch from the vPC peer switch
must be identical on both vPC peer switches.
(Optional)
Displays information about each vPC.
(Optional)
Copies the running configuration to the startup configuration.
Purpose
Enters configuration mode.
Selects an existing vPC domain on the switch, or creates
a new vPC domain, and enters the vpc-domain
configuration mode. There is no default domain-id ;
the range is from 1 to 1000.
Enters the MAC address that you want for the specified
vPC domain in the following format: aaaa.bbbb.cccc.
141
