Introduction and Features Summary
PEG
Processor
Processor Core
Rank
SCI
Storage Conditions
TAC
TDP
TOM
TTM
V
CC
V
SS
V
AXG
V
TT
V
DDQ
VLD
x1
x4
x8
x16
1.5
Related Documents
Refer to the documents in
Table 1.
Processor Documents
Intel® Core
®
Intel
Core
Addendum Specification Update
April 2010
Document Number: 323178-002
Term
PCI Express* Graphics. External Graphics using PCI Express Architecture. A
high-speed serial interface whose configuration is software compatible with the
existing PCI specifications.
The 64-bit, single-core or multi-core component (package)
The term "processor core" refers to Si die itself which can contain multiple
execution cores. Each execution core has an instruction cache, data cache, and
256-KB L2 cache. All execution cores share the L3 cache.
A unit of DRAM corresponding four to eight devices in parallel, ignoring ECC.
These devices are usually, but not always, mounted on a single side of a SO-
DIMM.
System Control Interrupt. Used in ACPI protocol.
A non-operational state. The processor may be installed in a platform, in a tray,
or loose. Processors may be sealed in packaging or exposed to free air. Under
these conditions, processor landings should not be connected to any supply
voltages, have any I/Os biased or receive any clocks. Upon exposure to "free air"
(i.e., unsealed packaging or a device removed from packaging material) the
processor must be handled in accordance with moisture sensitivity labeling
(MSL) as indicated on the packaging material.
Thermal Averaging Constant
Thermal Design Power
Top of Memory
Time-To-Market
Processor core power supply
Processor ground
Graphics core power supply
L3 shared cache, memory controller, and processor I/O power rail
DDR3 power rail
Variable Length Decoding
Refers to a Link or Port with one Physical Lane
Refers to a Link or Port with four Physical Lanes
Refers to a Link or Port with eight Physical Lanes
Refers to a Link or Port with sixteen Physical Lanes
Table 1
Document
TM
i7-600, i5-500 and i3-300 Mobile Processor Series Datasheet
TM
i7-620LE/UE, i7-610E and i5-520E Processor Series Datasheet
®
TM
Intel
Core
i7-620LE/UE, i7-610E, i5-520E and Intel
Description
for additional information.
®
Celeron
Document Number/
Location
http://www.intel.com
http://www.intel.com
®
Processor P4500, P4505 Series
Datasheet Addendum
13
