- Page 1 Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit User Guide November 2012 Document Number: 328076-001...
- Page 2 Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order. Copies of documents which have an order number and are referenced in this document, or other Intel literature, may be obtained by calling 1-800-548-4725, or go to: http://www.intel.com/design/literature.htm...
-
Page 3: Table Of Contents
J4C1-Select LVDS panel Operating Voltage ............18 Table 12. J3F2-Select eDP panel Operating Voltage ............. 18 Table 13. J2G1/J2G2/J2G3 USB Port ................. 19 Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit November 2012 User Guide Document Number: 328076-001... - Page 4 J1G3 Power Switch and HDD Indicator header ............22 Table 22. J1G1 Power Indicator Header ................23 Table 23. J1G2 Speaker Output Header ................23 Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit User Guide November 2012 Document Number: 328076-001...
-
Page 5: Revision History
Introduction Revision History Date Revision Description November 2012 Initial release. § Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit November 2012 User Guide Document Number: 328076-001... -
Page 6: Introduction
HDMI High Definition Multimedia Interface High Speed Database IMVP-6 Intel Mobile Voltage Positioning 6 ITP-XDP In-target-probe – eXtended debug port Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit User Guide November 2012 Document Number: 328076-001... - Page 7 Used to signify DIMM logic supply voltage Video Graphics Array Voltage Identification VREF Voltage reference Used to signify ground connection Used to signify signal termination voltage Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit November 2012 User Guide Document Number: 328076-001...
-
Page 8: Reference Documents
Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit Quick Start • DVD installer driver § Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit User Guide November 2012 Document Number: 328076-001... -
Page 9: Features
Minimum capacity of 256 MB using 512 Mb technology; Supports DDR3 frequency of up to 1600 MT/s with Ivy Bridge; Refdes on Board: DIMM1, DIMM 2 Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit November 2012 User Guide Document Number: 328076-001... - Page 10 Refdes on board: U2E2, U2E1 SATA 2x SATA III Ports SATA connector with 4 pin power header on board SATA III connector Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit User Guide November 2012 Document Number: 328076-001...
- Page 11 150W power supply adaptor Debug Interfaces CPU and PCH XDP On board CPU and PCH XDP Ports Connector Form Factor MINI- ITX § Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit November 2012 User Guide Document Number: 328076-001...
-
Page 12: Power Management
V5_A V3P3_A 3.3V V3P3_M 3.3V V1P05_M 1.05V V3P3 3.3V V1P8 1.8V V1P5 1.5V V0P85 0.85V- 0.95V V0P75 0.75V V1P05 1.05V Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit User Guide November 2012 Document Number: 328076-001... - Page 13 Power management VOLTAGE S0/M0 S3/M3 S4/M3 S5/M3 LEVEL V1P05_VTT 1.05V VCC_GFXCORE 0.4-1.25V VCC_CORE 0.35-1.5V § Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit November 2012 User Guide Document Number: 328076-001...
-
Page 14: Reference Board Summary
The following figures show the major components and jumpers and Table 6 gives a brief description of each component. Figure 2. Board Layout - Top view Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit User Guide November 2012... -
Page 15: Figure 3. Board Layout - Bottom View
Reference Board Summary Figure 3. Board Layout – Bottom view Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit November 2012 User Guide Document Number: 328076-001... -
Page 16: Table 6. Components List
DIMM1 (CH A) 204pin DDR3 non ECC Power push button SW2G1 SODIMM Connector DIMM2 (CH B) CPU Fan J7F1 U2D1 Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit User Guide November 2012 Document Number: 328076-001... -
Page 17: Connectors
2), then disconnect the jumper on that header. Remember that this header is not shorted with a jumper by default. (3) Turn on the board Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit November 2012 User Guide... -
Page 18: Table 8. J1D2-Clear/Keep Me Register Setting
Table 11. J4C1-Select LVDS panel Operating Voltage Setup Function 3.3V (Default) Table 12. J3F2-Select eDP panel Operating Voltage Setup Function 3.3V (Default) Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit User Guide November 2012 Document Number: 328076-001... -
Page 19: Header Pinout Configuration
5 and 7 are for TTL input while Pins 2, 4, 6 and 8 are for CMOS output. The factory default status is high level while the voltage range for IO signals is 0-5V. Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit November 2012... -
Page 20: J3C2/J3C1- Dual Channel Lvds Data Connector
LVDS 1 only. Note: LVDSA_X indicates to dual scan the odd line while LVDSB_X indicates to dual scan the even line. Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit User Guide November 2012 Document Number: 328076-001... -
Page 21: Embedded Display Port (Edp) Connector
It needs to set in the BIOS SETUP and select J1D1 jumper (Enable the Operating Voltage of LVDS and eDP) to select which interface is going to be used. Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit November 2012... -
Page 22: Front Panel Status Indicating And Control Connector
Front Panel Status Indicating and Control Connector Table 21. J1G3 Power Switch and HDD Indicator header Signal Name Signal Name PWRBTN# RESET# SATA_LED- 1-4: Power Button Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit User Guide November 2012 Document Number: 328076-001... -
Page 23: Power On And Reset Buttons
The POWER button is located at SW2G1 and the RESET button is located at SW1G1 Description Reference Designator Power Button SW2G1 Reset Button SW1G1 Processor U5E1 § Intel® Core™ i5-3610ME Processor (PGA) and Mobile Intel® QM77 Express Chipset Development Kit November 2012 User Guide Document Number: 328076-001...
