Processor Configuration Registers
6.2.33
PEG_CAPL - PCI Express-G Capability List
B/D/F/Type:
Address Offset:
Default Value:
Access:
Size:
Enumerates the PCI Express capability structure.
Table 56.
PEG_CAPL - PCI Express-G Capability List Register
Default
Bit
Access
Value
15:8
RO
7:0
RO
6.2.34
PEG_CAP - PCI Express-G Capabilities
B/D/F/Type:
Address Offset:
Default Value:
Access:
Size:
Indicates PCI Express device capabilities.
Table 57.
PEG_CAP - PCI Express-G Capabilities Register
Default
Bit
Access
15
RO
14
RO
13:9
RO
8
RW-O
7:4
RO
April 2010
Document Number: 323178-002
RST/
PWR
00h
Core
Pointer to Next Capability (PNC)
This value terminates the capabilities list. The Virtual Channel
capability and any other PCI Express specific capabilities that are
reported via this mechanism are in a separate capabilities list
located entirely within PCI Express Extended Configuration
Space.
10h
Core
Capability ID (CID)
Identifies this linked list item (capability structure) as being for
PCI Express registers.
RST/
Value
PWR
0b
Core
Reserved
0b
Core
Reserved
Reserved for TCS Routing Supported.
00h
Core
Interrupt Message Number (IMN)
Not Applicable or Implemented. Hard wired to 0.
1b
Core
Slot Implemented (SI)
0 = The PCI Express Link associated with this port is connected
1 = The PCI Express Link associated with this port is connected
BIOS Requirement: This field must be initialized appropriately
if a slot connection is not implemented.
4h
Core
Device/Port Type (DPT)
hard wired to 4h to indicate root port of PCI Express Root
Complex.
®
TM
Intel
Core
i7-620LE/UE, i7-610E, i5-520E and Intel
0/6/0/PCI
A0-A1h
0010h
RO
16 bits
Description
0/6/0/PCI
A2-A3h
0142h
RO; RW-O
16 bits
Description
to an integrated component or is disabled.
to a slot.
®
Celeron
®
Processor P4500, P4505 Series
Datasheet Addendum
111
