Table 63. LSTS - Link Status Register (Sheet 3 of 3)
Default
Bit Access
Value
3:0 RO
6.2.41

SLOTCAP - Slot Capabilities

B/D/F/Type:
Address Offset:
Default Value:
Access:
Size:
PCI Express Slot related registers allow for the support of Hot Plug.
Table 64. SLOTCAP - Slot Capabilities Register (Sheet 1 of 2)
Default
Bit Access
Value
31:19 RW-O 0000h
18 RW-O
17 RO
16:15 RW-O
® TM
Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel
Datasheet Addendum
122
RST/
PWR
0h Core Current Link Speed (CLS)
This field indicates the negotiated Link speed of the given PCI
Express Link.Defined encodings are:
0001b 2.5 GT/s PCI Express Link
All other encodings are reserved. The value in this field is
undefined when the Link is not up.
RST/
PWR
Core Physical Slot Number (PSN)
Indicates the physical slot number attached to this Port.
BIOS Requirement: This field must be initialized by BIOS to a
value that assigns a slot number that is globally unique within
the chassis.
1b Core No Command Completed Support (NCCS)
When set to 1b, this bit indicates that this slot does not
generate software notification when an issued command is
completed by the Hot-Plug Controller. This bit is only permitted
to be set to 1b if the hotplug capable port is able to accept
writes to all fields of the Slot Control register without delay
between successive writes.
0b Core Reserved for Electromechanical Interlock Present (EIP)
When set to 1b, this bit indicates that an Electromechanical
Interlock is implemented on the chassis for this slot.
00b Core Slot Power Limit Scale (SPLS)
Specifies the scale used for the Slot Power Limit Value.
00:
01:
10:
11:
If this field is written, the link sends a Set_Slot_Power_Limit
message.
®
Celeron
Processor Configuration Registers
Description
0/6/0/PCI
B4-B7h
00040000h
RW-O; RO
32 bits
Description
1.0x
0.1x
0.01x
0.001x
®
Processor P4500, P4505 Series
April 2010
Document Number: 323178-002
