Processor Configuration Registers
6.2.17

PMBASE6 - Prefetchable Memory Base Address

B/D/F/Type:
Address Offset:
Default Value:
Access:
Size:
This register in conjunction with the corresponding Upper Base Address register
controls the CPU to PCI Express-G prefetchable memory access routing based on the
following formula:
PREFETCHABLE_MEMORY_BASE =< address =< PREFETCHABLE_MEMORY_LIMIT
The upper 12 bits of this register are read/write and correspond to address bits
A[31:20] of the 40-bit address. The lower 8 bits of the Upper Base Address register are
read/write and correspond to address bits A[39:32] of the 40-bit address. This register
must be initialized by the configuration software. For the purpose of address decode
address bits A[19:0] are assumed to be 0. Thus, the bottom of the defined memory
address range is aligned to a 1-MB boundary.
Table 40.

PMBASE6 - Prefetchable Memory Base Address Register

Default
Bit Access
15:4 RW
3:0 RO
April 2010
Document Number: 323178-002
RST/
Value PWR
FFFh Core Prefetchable Memory Base Address (MBASE)
Corresponds to A[31:20] of the lower limit of the memory range
that is passed to PCI Express-G.
1h Core 64-bit Address Support (64-bit Address Support)
Indicates that the upper 32 bits of the prefetchable memory
region base address are contained in the Prefetchable Memory
base Upper Address register at 28h.
® TM
Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel
0/6/0/PCI
24-25h
FFF1h
RO; RW
16 bits
Description
®
Celeron
®
Processor P4500, P4505 Series
Datasheet Addendum
97
