Figure 25. Removing the Processor Air Duct (SR1530HCL/SR1530HCLS and

Installing the Processor Air Duct

1. Observe the safety and ESD precautions at the beginning of this book. See
Information" on page
2. Power down the server and unplug all peripheral devices and the AC power cable.
3. Remove the server system cover. For instructions, see
System Cover" on page
4. Lower the air duct into place, insert the two hooks at the front of the processor air
duct into the corresponding slots on the bracket behind the two system blower fans.
Use caution not to pinch or disengage cables that may be near or under the air duct.
See
Figure 27
Intel® Server System SR1530HCLR / SR1530HCLSR.
Server System User Guide
SR1530HCLR/SR1530HCLSR)
iii.
28.
Figure 26 for the Intel® Server System SR1530CL / SR1530CLR. See
for the Intel® Server System SR1530HCL / SR1530HCLS and the
AF001618
"Safety
"Removing the Server
