C
D
B
A
AF000670
Figure 57. Removing the Optical Drive from the Server System (SR1530CL/
SR1530CLR)
9. Remove the four screws that attach the brackets to the optical drive, as shown in the
following figure. Save these screws for future use.
AF000672
Figure 58. Removing the Brackets from the Optical Drive Bracket
(SR1530CL/SR1530CLR)
Server System User Guide 59
