10. HDD1 only: Route the power cable into the cable clip on the top of the hard drive
bracket.
11. Connect the data cables to the drive(s).
— If a drive is installed in the HDD0 carrier, connect the HDD0 data cable to the
— If a drive is installed in the HDD1 carrier, connect the HDD1 data cable to the
Note: The data cables are factory routed underneath the fan module. Use caution to make sure
you connect the cables between the server board and the hard drives. The cables are
labeled at each end.
12. Connect the power cables to the drive(s):
— If a drive is installed in the HDD1 carrier, attach the connector on the daisy
— If a drive is installed in the HDD0 carrier, attach the middle connector on the
Figure 39. Connecting Hard Drive Power and Data Cables (SR1530CL/
Server System User Guide
SATA 0 connector on the server board. See letter "A" in
SATA 1 connector on the server board. See letter "B" in
chain power cable that is closest to the power supply to the HDD1 connector.
See letter "D" in Figure
daisy chain power cable to the HDD0 power connector. See letter "C" in
Figure 39.
39.
