Data Cable Routing (SR1530CL/SR1530CLR)

(
A
B
100
C
D
Optical Device
B
HDD 0
D
A.
SATA 1 to HDD1
B.
SATA 0 to HDD0

Figure 99. Data Cable Routing (SR1530CL/SR1530CLR)

C
A
HDD 1
C.
Front control panel
D.
Front panel USB
AF001207
Server System User Guide
